2026 / 2025 North Vector Race Foil Board



2026 / 2025 North Vector Race Foil Board

Wing Race Foilboard

Product Code: 85013.250170

Sizes: 4ft 7in | 5ft 0in | 5ft 4in

The Vector is precisely tuned for sustained flight and top speeds, even in challenging conditions. Light, long and narrow for early lift to foil, its aero-shaped profile reduces drag when heeled over, enabling you to point higher upwind, accelerate out of tacks and

The North Digital Product Passport offers a range of free, brand-new benefits for you and your gear, including Lost & Found Services, Theft Protection, and comprehensive Product Info. Plus, you can become a Club North Member for free, enjoying exclusive perks and rewards.

Features

  • Aero/Hydro Hull Design for reduced drag and additional lift
  • Rounded rails prevent catching in chop and swell – so you can push harder
  • DropBox (165x90mm) and Tuttlebox Foil Mast Mount options
  • Narrow outline with raised bottom shape towards rails lets you heel over more for higher upwind angles
  • Sharply defined low-drag tail release edge
  • V-Strap Inserts
  • Sizing tailored to provide stability and agility for every rider’s weight

Materials

  • Full-wrap carbon PVC sandwich construction

Item Includes: DropBox Screw Pack (4x M8x30mm, 4x T-Nuts). *Deep TuttleBox screws and washers are not included - requires 13mm washers with a min thickness of 1.5 mm.

TECHNOLOGY

Carbon with Full PVC Wrap

A strong, light and efficient full carbon outer shell sits over a thin layer of high-density PVC foam, which wraps the entire board for maximum total breakage strength and impact resistance.


Lightweight, long and narrow

Engineered to reduce windage for faster flying, the Vector is shaped for speed, fast on the water and fast up onto the foil.


Intuitive Concaved Deck

The highly concaved deck allows more intuitive foot positioning and also acts like a counterbalance, so you don’t feel like you are heeling over as far on the board.


Display mount inserts (76x39mm)

Includes insert mounting points for Sailmon Max or similar performance-trackers with a custom adaptor plate. Fits 4x 6.3x25 Countersunk Self-Tapping Screws.


GORE Waterproof 2-way Vent

The EPS core of a high-volume board is affected by extreme temperature changes. To prevent air pressure build-up a two-way GORE Protective Vent is factory-fitted on the top deck.


Non-abrasive max-traction deckgrip

For a more intuitive and direct connection to your foil, high traction non-abrasive heat-embossed deckpads with tactile and visual stance reference allow fast, easy foot placement.


V-Strap Inserts

Multiple positioning options for each strap allow you to personalise your stance—or go strapless. V-strap inserts accommodate goofy or natural riding. Straps sold separately.


Race bred Aero/Hydro Hull

Engineered aerodynamically to reduce windage, with rounded hull and rails to prevent catching in chop and swell, so you can push harder on the course. Faster speeds, with touchdown recovery.


DropBox and Tuttle box options

The best of both worlds. The Vector has a DropBox track compatible with most foil systems and a carbon Deep Tuttle box, so you can upgrade to a more race-dedicated foil system as you progress.


Includes Foil Mounting Hardware

4x Titanium M8x30mm DropBox screws and T-nuts are supplied with the Vector. You’ll find the screws installed into the 90mm mast tracks.



Digital Product Passport

You’ll find a unique QR code printed on your board. Scan this QR to register the product and unlock benefits like Lost & Found Services, Theft Protection and free Club North membership.
